Used 20 Ton Crawler Excavator with 1.0 m3 Bucket Capacity and Liyuan Hydraulic Valve

Showroom Location : None

Place of Origin : henan

Operating Weight : 20 Ton

Bucket capacity : 1.0, 1,0 m3

Machine Weight : 20500 KG

Hydraulic Cylinder Brand : HYDAC

Hydraulic Pump Brand : Vickers

Hydraulic Valve Brand : Liyuan

Engine Brand : Other

Power : 108/200

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Core Components : Pressure vessel, Gearbox, Engine

Year : 2019

Working hours : 40001-50000

Tonnage (ton) : 20

Machine working weight : 20500KG

Boom length : 5700MM

Stick length : 2900MM

Rotation speed : 11,6 tr/min

Swing torque : 74,4Nm

Walking speed : 5.9km/h

Maximum traction : 129kN

Stick digging forc : 99 kN

Packaging Details : NUDE

Port : SHANGHAI

Supply Ability : 10 Unit/Units per Week

Price : $32,500.00/units 1-4 units

Contact Now

Product Description

Used 20 Ton Crawler Excavator with 1.0 m3 Bucket Capacity and Liyuan Hydraulic Valve

Product Details

Large engine power, mining power, C1.1 large capacity 3 cylinder diesel engine, 16.1kW total power

Safe and reliable, open cab, maintain a large space, 3 side service door, sufficient material, reliable quality

High configuration, convenient operation, single handle walking + floating shovel (bulldozer mode), constant speed cruise, high-end configuration, standard bidirectional hydraulic pipeline, tailless design + adjustable body width, longitudinal enjoy free shuttle

Luxurious and comfortable, suspension seat, comfortable driving for a day, continuous flow hammer, transparent skylight, clear sight above the equipment, safe and convenient construction, work light delay off, illuminate the way home, USB charging hole

Product Paramenters

Tonnage (ton)	20
Working weight of the machine (kg)	22000
Bucket capacity (m3)	1.19
Bucket rod length (mm)	5700
Rotational speed (rpm)	2900
Walking speed (km/h)	5.7
Ground specific pressure (Kpa)	2950
Bucket digging force (kN)	150
Bucket rod digging force (kN)	106
Maximum traction (kN)	205
Rated power (kw/rpm)	118/1650
Displacement (L)	7.01
Cylinder diameter × stroke (mm)	105×135
Maximum flow rate of main pump (l/min)	429
Fuel tank (L)	345
Hydraulic tank (L)	128
Hydraulic system (L)	218
Engine oil replacement (L)	415
Coolant (L)	32
Total length of transport (mm)	9530
Total transport height (mm)	2980
Track plate width (mm)	2960
Total track width (mm)	600
Back end turning radius (mm)	2830
Maximum digging depth (mm)	6720
Maximum excavation height (mm)	9370
Maximum unloading height (mm)	6490
Maximum vertical digging depth (mm)	5190

Company Profile

Used 20 Ton Crawler Excavator with 1.0 m3 Bucket Capacity and Liyuan Hydraulic Valve Images
